MMC3630KJ Memsic Inc.
Same model may have multiple batches, images only for reference.

MMC3630KJ

Part No MMC3630KJ
Manufacturer Memsic Inc.
Catalog Magnetic Sensors - Linear, Compass (ICs)
Description MAGNETIC SENSOR 3-AXIS 1.2X1.2MM
Datasheet
MMC3630KJ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Magnetic Sensors - Linear, Compass (ICs)
Mfr Memsic Inc.
Package Tape & Reel
Product Status Active
Technology Magnetoresistive
Axis X, Y, Z
Output Type I2C
Sensing Range ±3mT
Voltage - Supply 1.62V ~ 3.6V
Current - Supply (Max) 300µA
Resolution 16 b
Bandwidth 600Hz
Temperature Range - Operating -40°C ~ 85°C
Features Internal Magnet, Temperature Compensated
Supplier Device Package 8-BGA (1.2x1.2)
Mounting Type Surface Mount
Package / Case 8-WFBGA, FCBGA
Base Product Number MMC3630
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 831203-MMC3630KJ
Ultra Librarian 3D Model Ultra Librarian MMC3630KJ CAD Model

Description

The MMC3630KJ is a magnetoresistive linear magnetic sensor designed for various applications.

  • Voltage Range: 1.62V to 3.6V
  • Maximum Supply Current: 300µA
  • Output Interface: I2C
  • Bandwidth: 600Hz
  • Sensing Range: ±3mT
  • Resolution: 16 bits
  • Mounting Type: Surface mount
  • Axes: X, Y, Z
