SMBJ190A

Name: SMBJ190A
Brand: MERITEK ELECTRONICS CORPORATION
SKU: 668784
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMBJ190A
Manufacturer	MERITEK ELECTRONICS CORPORATION
Catalog	TVS - Diodes
Description	TVS DIODE 190VWM 307.8VC / 307.8V Clamp 1.95A Ipp Tvs Diode Surface Mount
Datasheet	SMBJ190A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	MERITEK ELECTRONICS CORPORATION
Series	SMBJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	190V
Voltage - Breakdown (Min)	211V
Voltage - Clamping (Max) @ Ipp	307.8V
Current - Peak Pulse (10/1000µs)	1.95A
Power - Peak Pulse	600W
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	DO-214AA (SMB)
Standard Package	20 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	668784-SMBJ190A
Ultra Librarian 3D Model	Ultra Librarian SMBJ190A CAD Model

Alternative Products

Description

The SMBJ190A is a Zener-type TVS diode designed to protect electronic components from transient voltage events. It is part of the SMBJ series and comes in a surface mount package.

Voltage Reverse Standoff: 190V
Voltage Breakdown: 211V
Clamping Voltage: 307.8V @ a peak pulse power of 600W
Channel: Unidirectional
Current Peak Pulse: 1.95A
Suitable for: General-purpose circuit protection
Operating Temperature Range: -55°C to 150°C
Active Product: Manufactured by Meritek Electronics Corporation
