Microchip Technology's AT24C16B-TSU-T EEPROM

The AT24C16B-TSU-T is a high-performance, 16-Kbit Electrically Erasable Programmable Read-Only Memory (EEPROM) device brought to you by Microchip Technology. This integrated circuit is designed for optimal data storage with a focus on reliability, endurance, and low-power consumption, making it an excellent choice for a wide array of applications ranging from industrial, automotive, to consumer electronics.

Key Features

• Memory Size: The AT24C16B-TSU-T offers 16Kbits of memory, organized as 2,048 x 8 bits, which is suitable for storing configurations, settings, or small amounts of data that need to be preserved during power cycles.
• Interface Type: It utilizes the popular I²C (Two-Wire) serial interface, allowing for easy integration into most microcontroller-based systems and ensuring compatibility with a wide range of devices.
• Operating Voltage: The device supports a voltage range of 1.7V to 5.5V, accommodating various system power supplies and enabling its use in both 3.3V and 5V systems.
• Write Cycle Time: Fast write cycle times of 5 ms (typical) allow for quick data updates, enhancing performance in applications where data is frequently changed.
• Endurance: The EEPROM is rated for a high write endurance of 1 million write cycles and a data retention period of 100 years, ensuring the longevity and durability of the stored data.
• Temperature Range: It is operational across the industrial temperature range of -40°C to +85°C, making it robust enough for demanding environments.
• Packaging: Supplied in a surface-mount, 8-pin TSSOP package, the AT24C16B-TSU-T is designed for automated assembly processes and is space-efficient for PCB designs.

Applications

The AT24C16B-TSU-T EEPROM is versatile and can be utilized in various applications such as:

• Parameter and configuration storage for industrial systems
• Non-volatile memory for automotive applications
• Calibration data storage for sensors and instrumentation
• User preference storage in consumer products
• Real-time clock (RTC) backup in computing devices

With its robust design, ease of integration, and Microchip's commitment to quality, the AT24C16B-TSU-T is a reliable choice for designers looking to enhance their systems with non-volatile memory solutions.
