Microchip Technology's ATMEGA169P-15AT

The ATMEGA169P-15AT is a high-performance microcontroller unit (MCU) from Microchip Technology, designed to offer a blend of power efficiency and processing capability. This 8-bit MCU is based on the advanced RISC architecture and is part of the popular AVR® family, known for their ease of use and robust performance in a wide array of applications.

With its operating voltage ranging from 2.7V to 5.5V, the ATMEGA169P-15AT is versatile and can adapt to various power requirements, making it suitable for battery-operated devices as well as those connected to power supplies. The device features a maximum clock frequency of 16MHz, which provides a balanced trade-off between speed and power consumption.

One of the standout features of this MCU is its 16KB of in-system self-programmable flash memory. This generous amount of memory allows for complex applications and the flexibility to update firmware in the field. Additionally, the ATMEGA169P-15AT comes with 512 bytes of EEPROM and 1KB of internal SRAM, offering ample space for data storage and manipulation.

The device is equipped with a range of peripherals that enhance its functionality. These include a 10-bit analog-to-digital converter (ADC) with up to 8 channels, allowing for precise analog signal measurement. It also has a byte-oriented Two-Wire Serial Interface, which is compatible with I2C for multi-master communication. The ATMEGA169P-15AT supports SPI serial port for high-speed data transfer and a programmable watchdog timer with an internal oscillator for reliable system reset.

For designers concerned with user interface, this MCU includes an LCD controller that supports up to 25 segments, enabling the creation of small, informative displays. It also has 32 general-purpose I/O lines, which provide the flexibility to connect a wide range of external devices.

The ATMEGA169P-15AT is packaged in a 64-pad QFN/MLF, which is designed for space-constrained applications. Its robust design and comprehensive feature set make it an ideal choice for applications in automotive, industrial, consumer electronics, and many other fields that require a reliable and capable MCU.

Overall, the ATMEGA169P-15AT from Microchip Technology is a compact, feature-rich MCU that offers designers a powerful platform for developing sophisticated and power-conscious applications.
