Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 4.4V
Maximum Input Voltage 30V
Nominal Output Voltage (Min/Fixed) 2V
Maximum Output Voltage 24V
Output Current 1A
Frequency - Switching 500kHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-MSOP
Win Source Part Number 1074748-MCP16311-E/MS
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MCP16311-E/MS CAD Model

Description

Microchip Technology's MCP16311-E/MS: High-Efficiency, Compact DC-DC Converter

The MCP16311-E/MS is a highly integrated, compact, and efficient step-down DC-DC converter from Microchip Technology, designed to meet the needs of a wide range of electronic applications. This versatile component is capable of delivering up to 600 mA of continuous current at output voltages as low as 2V, making it an excellent choice for powering advanced microcontrollers, sensors, and other low-power devices in space-constrained environments.

Encased in a small 8-lead MSOP (Micro Small Outline Package), the MCP16311-E/MS offers a reduced footprint on printed circuit boards, which is crucial for modern portable and wearable technology, as well as for industrial and automotive applications where space is at a premium. Its high level of integration minimizes the need for external components, simplifying design and reducing overall system cost.

The MCP16311-E/MS operates over a wide input voltage range of 4.4V to 30V, accommodating various power supplies and battery configurations. This flexibility ensures that the device can adapt to multiple applications without the need for significant redesign. Its high efficiency, up to 96%, is achieved through an advanced PWM (Pulse Width Modulation) technique, which also helps to minimize power loss and heat generation.

Key features of the MCP16311-E/MS include an adjustable output voltage, which allows for precise regulation tailored to specific application requirements. It also incorporates a range of protective features, such as overtemperature protection, undervoltage lockout, and overcurrent limiting, enhancing the reliability and longevity of the end product. The device operates at a fixed frequency of 500 kHz, which provides an optimal balance between efficiency and component size, allowing for the use of small, low-cost inductors and capacitors.

In summary, the MCP16311-E/MS from Microchip Technology is a powerful, versatile, and space-efficient solution for modern electronic designs that require a compact, high-efficiency power converter. With its robust feature set and ease of integration, it represents an excellent choice for engineers looking to optimize their power management systems.
