MCP6004-I/ST Operational Amplifier from Microchip Technology

The MCP6004-I/ST is a quad operational amplifier (op-amp) designed by Microchip Technology, a leader in microcontroller, mixed-signal, analog, and Flash-IP solutions. This particular model is part of the MCP600x family, known for its low power consumption and general-purpose utility in a wide range of electronic applications.

Key Features

• Supply Voltage Range: The MCP6004-I/ST can operate on a single supply voltage ranging from 1.8V to 6.0V, making it versatile for both low-power and standard applications.
• Low Quiescent Current: With a quiescent current of just 100 µA (typical) per amplifier, this op-amp is an excellent choice for battery-powered devices and energy-efficient designs.
• Rail-to-Rail Output: The rail-to-rail output swing ensures maximum dynamic range, which is especially useful when operating at lower supply voltages.
• Extended Temperature Range: It is designed to function over an extended temperature range, from -40°C to +125°C, suitable for industrial and automotive applications.
• Gain Bandwidth Product: The device offers a gain bandwidth product of 1 MHz (typical), which is sufficient for low-frequency applications such as sensor interfacing, A/D convertor driving, and general-purpose amplification.

Package and Reliability

The MCP6004-I/ST comes in a 14-pin TSSOP (Thin Shrink Small Outline Package) that is ideal for space-constrained applications. The TSSOP package is recognized for its reliability and robustness, ensuring stable performance across various conditions.

Applications

This operational amplifier is well-suited for a range of applications, including:

• Portable Instrumentation
• Analog Filters
• Signal Conditioning
• Data Acquisition Systems
• Consumer Electronics
• Automotive Electronics

The MCP6004-I/ST offers a balanced combination of performance, power efficiency, and versatility, making it a go-to choice for engineers and designers looking to optimize their analog circuit designs. With its reliable operation and Microchip's commitment to quality, this operational amplifier is an excellent component for your next electronic project.
