Microchip MCP7940NT-I/SN Real-Time Clock/Calendar

The MCP7940NT-I/SN is a highly integrated Real-Time Clock/Calendar (RTCC) from Microchip Technology, designed for effective time tracking and control in embedded systems. This compact, low-power device is packed with features that make it ideal for a wide range of applications including smart energy, home appliances, industrial control systems, and consumer electronics.

One of the standout features of the MCP7940NT-I/SN is its built-in 64-byte battery-backed SRAM, which ensures that data is retained even when the main power supply is lost. This RTCC operates over the standard I2C™ bus, allowing easy integration into most microcontroller-based systems. With a battery switchover circuit included, the device can automatically switch to backup power, ensuring uninterrupted timekeeping.

The MCP7940NT-I/SN offers a full calendar system with hours, minutes, seconds, days, weeks, months, and years. It also accounts for leap years up to the year 2399, providing a long-term, maintenance-free solution. Additionally, it includes features such as digital trimming for time calibration, which can compensate for crystal frequency drifts due to temperature changes or other factors.

Alarm functions are another key feature of this device, which can be programmed to trigger on a minute, hour, day, or date basis. This flexibility allows for precise scheduling of events or tasks. The MCP7940NT-I/SN also provides a programmable clock output which can be used for various purposes, including external component clocking or as a system wakeup signal.

With a wide operating voltage range of 1.8V to 5.5V, the MCP7940NT-I/SN is versatile for different power environments. Its temperature range of -40°C to +85°C ensures reliable operation under varying conditions. The device comes in an 8-pin SN (SOIC) package, making it easy to incorporate into PCB designs without taking up significant space.

In summary, the Microchip MCP7940NT-I/SN is a feature-rich, reliable RTCC solution that provides precise timekeeping, low power consumption, and a host of programmable features to meet the needs of modern electronic systems.
