Microchip Technology MIC2101YML-TR Step-Down (Buck) Regulator

The MIC2101YML-TR from Microchip Technology is a high-performance, synchronous step-down (buck) regulator designed to deliver efficient power management for a wide range of applications. Encased in a compact 10-MLF® package, this regulator is an ideal solution for space-constrained environments.

Key Features

• Input Voltage Range: The MIC2101YML-TR operates with an input voltage range of 4.5V to 19V, making it versatile for various systems that require different power levels.
• Output Voltage: It provides an adjustable output voltage that can be set from 0.8V to 5.5V with an external resistor divider, catering to the needs of low-voltage power rails.
• High Efficiency: With its synchronous operation, the MIC2101YML-TR achieves high efficiency, which is particularly beneficial for reducing thermal stress and improving system reliability.
• Current Capability: The device can deliver up to 2A of continuous output current, suitable for powering a wide range of ICs and embedded systems.
• Thermal Management: It features an internal over-temperature protection that safeguards the device under high power operation or abnormal conditions.
• Stability: The MIC2101YML-TR is stable with ceramic output capacitors, ensuring reliable performance and simplifying the design process.
• Protection Features: It includes under-voltage lockout, over-current protection, and a thermal shutdown feature to enhance the safety and durability of the application.

Applications

The MIC2101YML-TR is suitable for a variety of applications, including:

• Point-of-Load (POL) conversions
• Networking and telecommunications equipment
• Computer peripherals and servers
• Industrial and medical equipment

With its robust feature set and compact footprint, the MIC2101YML-TR from Microchip Technology provides designers with a reliable and flexible power management solution that meets the stringent requirements of modern electronic systems.
