Microchip Technology's PIC18LF2620-I/SP Microcontroller

The PIC18LF2620-I/SP is a high-performance microcontroller unit (MCU) from Microchip Technology, a leader in the field of smart, connected, and secure embedded control solutions. This particular MCU is part of Microchip's renowned PIC18F series, which is designed to offer increased flexibility, compatibility, and power efficiency for a wide range of applications.

Key Features:

• Core: The device is built on a high-performance PIC18 8-bit architecture with an Enhanced Flash program memory.
• Speed: It operates at a maximum frequency of 40 MHz, providing robust processing capabilities for complex tasks.
• Memory: It includes 64 KB of flash program memory, 3.8 KB of RAM, and 256 bytes of EEPROM data memory, allowing for efficient data storage and retrieval.
• I/O Ports: The MCU features 25 I/O pins which offer versatility in interfacing with peripherals and external devices.
• Analog-to-Digital Converter (ADC): It comes with a 10-bit, up to 13-channel ADC, enabling precise analog signal measurement.
• Supply Voltage: It operates at a low voltage range of 2.0V to 5.5V, making it suitable for battery-operated and portable applications.

Connectivity:

The PIC18LF2620-I/SP provides a variety of serial communication options including:

• USART/SCI for serial communication
• SPI for high-speed synchronous data transfer
• I²C for multi-master communication

Low Power Features:

Designed for power-sensitive applications, the microcontroller includes several power management features such as:

• Power-on Reset (POR)
• Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
• Selectable sleep and idle modes for power conservation

Package and Quality:

The MCU comes in a 28-pin SPDIP (Single In-line Package) which is ideal for prototyping, as it is easy to handle and integrate into a variety of circuit boards. Microchip ensures high standards of quality and reliability for the PIC18LF2620-I/SP, making it a trusted choice for industrial, automotive, and consumer applications.
