Product Overview: PIC24FJ256GA702T-I/ML

The PIC24FJ256GA702T-I/ML is a high-performance, 16-bit microcontroller designed and manufactured by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This microcontroller is part of the PIC24F family and is well-suited for a range of applications, including industrial control systems, automotive applications, consumer electronics, and Internet of Things (IoT) devices.

Key Features

• Core: The device features a 16-bit modified Harvard architecture with a C30 compiler-friendly instruction set, which includes a 24-bit wide instruction word and 16-bit wide data path.
• Memory: It comes equipped with 256 KB of flash memory and 16 KB of RAM, providing ample space for complex applications and data storage.
• Speed: The microcontroller operates at a maximum internal clock frequency of 32 MHz, offering a balanced performance for power-sensitive designs.
• Temperature Range: The industrial temperature range of -40°C to +85°C ensures reliable operation in harsh environments.
• Package: Housed in a compact 44-pin QFN (Quad-Flat No-leads) package, the PIC24FJ256GA702T-I/ML is designed for space-constrained applications.
• I/O and Peripherals: It boasts a rich set of peripherals, including UART, SPI, I2C modules for serial communication, as well as PWM outputs and analog inputs for interfacing with sensors and actuators.
• Power Management: The device features flexible power management options with Power-on Reset (POR), Power-up Timer (PWRT), Oscillator Start-up Timer (OST), Idle and Sleep modes, which help in reducing overall power consumption.
• Analog Features: The microcontroller includes a 10-bit, up to 24-channel Analog-to-Digital Converter (ADC), which provides precise analog signal conversion for sensor interfacing.
• Debugging: It supports In-Circuit Serial Programming™ (ICSP™) and In-Circuit Debug (ICD) via two pins, simplifying the development and testing process.

Applications

The versatility of the PIC24FJ256GA702T-I/ML allows it to be integrated into a wide array of applications. Its robust design and rich feature set make it ideal for advanced control systems, automotive electronics, medical devices, smart sensors, and other embedded systems that require efficient power management, reliable data processing, and communication capabilities.

Microchip Technology's commitment to quality ensures that the PIC24FJ256GA702T-I/ML microcontroller is a dependable choice for engineers and designers looking to develop high-performance, low-power applications with a compact footprint.
