The 2081235 is a Micro-Fit 3.0 connector manufactured by Molex, LLC. It is a small, high-density power connector system designed for applications requiring both power and signal in a compact package. This connector is known for its secure locking mechanism and robust construction, ensuring reliable connections in demanding environments.

Applications

• Consumer electronics
• Industrial automation
• Networking equipment
• Telecommunications
• Medical devices

Features

• Micro-Fit 3.0 connector system
• High-density design
• Positive locking mechanism
• Fully polarized housing
• Terminal position assurance (TPA)
• Available in various circuit sizes

Benefits

• Space savings due to its compact size, allowing for smaller and more efficient designs.
• Reliable connections ensured by the positive locking mechanism, preventing accidental disconnections.
• Reduced assembly time and improved accuracy with the fully polarized housing, preventing mis-mating.
• Enhanced connection integrity due to the terminal position assurance (TPA), ensuring proper terminal seating.
• Design flexibility with the availability of various circuit sizes, catering to different application needs.

Additional Details

The Micro-Fit 3.0 connector system is designed to meet the growing demand for smaller, more powerful connectors. The 2081235 part number specifically identifies a particular configuration within the Micro-Fit 3.0 family, which could include the number of circuits, housing material, and plating options. The positive locking feature provides an audible click when the connector is fully mated, providing user feedback. The TPA feature adds an extra layer of security by preventing terminals from backing out of the housing.

Technical Specifications (Typical):

• Pitch: 3.0 mm
• Current Rating: Refer to datasheet for specific current rating based on wire gauge and number of circuits
• Voltage Rating: Refer to datasheet for voltage rating
• Operating Temperature: Refer to datasheet for operating temperature range
• Contact Material: Typically brass or phosphor bronze with tin or gold plating
