The Molex 39-00-0048 is a rectangular connector housing, designed for wire-to-board connections. This housing is part of the Molex Standard .093" series, a widely recognized and reliable interconnect system used across various industries. It accepts crimp terminals to create a secure and robust electrical connection.

Applications:

• Consumer electronics requiring internal wire-to-board connections.
• Industrial equipment where robust and reliable signal and power connections are needed.
• Automotive applications such as wiring harnesses for various electronic control units.
• Telecommunications equipment for connecting internal modules and boards.
• Power supplies for connecting internal wiring to PCBs.

Features:

• Durable nylon construction for reliable performance in harsh environments.
• Accepts standard .093" series crimp terminals.
• Polarization features to prevent mismating.
• Positive locking mechanism ensures secure connections.
• Compact design for high-density applications.

Benefits:

• Provides a secure and reliable electrical connection.
• Reduces assembly time with easy-to-use crimp terminals.
• Prevents accidental disconnections due to vibration or shock.
• Ensures proper mating with polarization features.
• Offers a cost-effective solution for wire-to-board connections.

Additional Details:

The 39-00-0048 housing is typically used with Molex 0.093" series terminals such as the 02-09-1104 or 02-09-1105. The specific wire gauge accepted depends on the terminal used. The housing is made of nylon, providing good electrical insulation and mechanical strength. It is designed to withstand a wide range of operating temperatures. It's crucial to use the correct crimping tool to ensure a proper and reliable crimp connection. Refer to the Molex documentation for the appropriate terminal and crimping tool selection. This part is often used in conjunction with corresponding header connectors on the PCB to establish a complete wire-to-board connection.
