The Molex 43045-0818 is a Micro-Fit 3.0™ connector header, designed for wire-to-board applications requiring a robust and reliable connection. This eight-circuit, dual-row header features a through-hole mounting style and a positive locking mechanism, ensuring secure mating with compatible receptacles. Its compact size makes it ideal for high-density applications where space is limited.

Applications:

• Power Supplies
• Consumer Electronics
• Industrial Automation Equipment
• Robotics
• Telecommunications Equipment
• Automotive Electronics
• Medical Devices

Features:

• Micro-Fit 3.0™ Design: Offers a compact size with a 3.0mm pitch for high-density applications.
• Eight Circuits: Provides eight individual connection points for versatile signal and power routing.
• Dual-Row Configuration: Maximizes circuit density within a small footprint.
• Through-Hole Termination: Ensures a strong and reliable mechanical and electrical connection to the PCB.
• Positive Locking: Securely mates with compatible Molex receptacles, preventing accidental disconnections.
• High-Temperature Thermoplastic: Allows for use in reflow soldering processes.
• Polarization: Prevents incorrect mating with the receptacle.
• Tin Plating: Provides good conductivity and solderability.

Benefits:

• Space Saving: The compact Micro-Fit 3.0™ design reduces the overall size and weight of the application.
• Secure Connection: The positive locking feature ensures a stable and reliable connection, even in high-vibration environments.
• Easy Installation: Through-hole termination simplifies the soldering process and reduces assembly time.
• Versatile Application: Suitable for a wide range of applications due to its compact size, high current carrying capabilities, and secure locking.
• Increased Reliability: High-quality materials and construction ensure long-term reliability.
• Reduced Mismatch Risk: Polarization feature prevents damage due to incorrect mating.

Additional Details:

The Molex 43045-0818 is designed to mate with Molex Micro-Fit 3.0™ receptacles. It has a current rating of up to 5.0A per circuit. The housing material is a high-temperature thermoplastic, allowing it to withstand reflow soldering temperatures. This connector is RoHS compliant.
