502585-1270 Real Image
Same model may have multiple batches, images only for reference.

502585-1270

Part No 502585-1270
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Wire to Board RCP 12 POS 1.5mm Solder RA SMD CLIK-Mate™ T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Case / Package SIL
Color Beige
Connector Type Center Strip Contact, Receptacle
Contact Gender Female
Contact Material Copper
Contact Plating Tin
Country of Origin JP
Current Rating 2 A
Fastening Type Latch
Gender Receptacle
Glow Wire Compliant Non-compliant
Housing Material Thermoplastic
Mount Surface Mount
Number of Circuits 12
Number of Contacts 12
Number of Pins 12
Number of Positions 12
Number of Rows 1
Orientation Right Angle
Pitch 1.5 mm
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 100 V
Win Source Part Number 1157884-502585-1270
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 502585-1270 CAD Model

Description

The 1157884-502585-1270 is a 12 position, 1.5mm pitch, center strip contact, receptacle connector manufactured by Molex, LLC.

  • Housing Material: Thermoplastic
  • Contact Material: Copper
  • Voltage Rating: 100V
  • Current Rating: 2A
  • Mounting Type: Surface Mount
  • Fastening Type: Latch
  • Contact Plating: Tin
  • Orientation: Right-Angle
  • RoHS Compliant: Yes
  • Radiation Hardening: No
  • Application: Circular connectors - housings
