The Molex 78171-0004 is a Micro-Fit 3.0 receptacle housing. This component is part of the Micro-Fit 3.0 connector system, designed for high-density wire-to-wire and wire-to-board applications where space is a premium.

Applications

• Consumer electronics
• Automotive industry
• Telecommunications equipment
• Medical devices
• Industrial automation

Features

• Micro-Fit 3.0 connector system
• 4 circuits
• Single row
• Receptacle housing
• 3.0mm pitch

Benefits

• Provides a compact and reliable connection for wire-to-wire and wire-to-board applications.
• Enables high-density packaging due to its small footprint.
• Ensures secure mating with compatible Micro-Fit 3.0 headers or plugs.
• Suitable for a wide range of applications due to its versatile design.
• Durable construction ensures long-term performance and reliability.

Technical Specifications

The Molex 78171-0004 has the following specifications:

• Number of Circuits: 4
• Number of Rows: 1
• Pitch: 3.0mm
• Connector Type: Receptacle Housing
• Material: UL 94V-0 rated thermoplastic
• Color: Varies, typically black
• Operating Temperature: -40°C to +105°C
• Voltage Rating: 600V
• Current Rating: 8.5A per circuit

The 78171-0004 receptacle housing is designed to be used with Micro-Fit 3.0 crimp terminals. This connector ensures a secure and reliable connection in space-constrained environments.
