87831-0420 Real Image
Same model may have multiple batches, images only for reference.

87831-0420

Part No 87831-0420
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 4 POS 2mm Solder ST Thru-Hole Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 3.5814 mm
Contact Plating Gold
Country of Origin SG
Current Rating 2 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Thermoplastic
Lead Free Yes
Lead Pitch 2 mm
Maximum Operating Temperature 105 °C
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 4
Number of Contacts 4
Number of Positions 4
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Row Spacing 2.0066 mm
Termination Solder
Voltage Rating 125 V
Voltage Rating (DC) 125 V
Win Source Part Number 1024318-87831-0420
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 87831-0420 CAD Model

Description

The Molex, LLC 1024318-87831-0420 is a 4 position, 2mm pitch, black colored male vertical through-hole connector.

  • Positions: 4
  • Pitch: 2mm
  • Color: black
  • Gender: male
  • Orientation: vertical
  • Mounting: through-hole
  • Rows: 2
  • Row Spacing: 2.0066mm
  • Contact Material: brass
  • Housing Material: thermoplastic
  • Voltage Rating: 125V
  • Current Rating: 2A
  • Contact Resistance: 30 mΩ
  • Insulation Resistance: 1 GΩ
  • RoHS Compliant: yes
  • Working Temperature Range: -55°C to 105°C
  • Application: circular connector housings
