The Molex 87832-5623 is a Micro-Latch connector housing. It's designed to provide secure and reliable connections in a compact form factor. It belongs to Molex's Micro-Latch series, which is known for its positive locking mechanism and high-density capabilities.

Applications

• Consumer Electronics: Used in smartphones, tablets, and other portable devices for internal connections requiring a small footprint.
• Automotive Electronics: Employed in automotive applications for connecting sensors, actuators, and control units where space is limited.
• Industrial Equipment: Used in industrial machinery and control systems for reliable signal and power connections.
• Medical Devices: Found in medical equipment where secure connections are essential and space is at a premium.
• Data and Telecommunications: Used in networking equipment and communication devices for signal transmission.

Features

• Number of Circuits: This likely varies based on the specific configuration, but typically this series features multiple circuits. Research suggests it might have 6 circuits.
• Pitch: 1.25mm pitch for high-density connections.
• Housing Material: Durable plastic construction, often with a UL 94V-0 flammability rating for safety.
• Color: Natural (usually white or off-white).
• Polarization: Polarized design to prevent mismating.
• Latch Style: Micro-Latch locking mechanism for secure retention.

Benefits

• Space Saving: The small 1.25mm pitch allows for high-density connections in space-constrained applications.
• Secure Connection: The Micro-Latch design ensures a reliable connection, preventing accidental disconnections, especially in vibration-prone environments.
• Easy Assembly: Designed for easy assembly with compatible Molex crimp terminals.
• Versatile: Suitable for a wide range of applications requiring compact and reliable connections.
• Durable: Constructed from high-quality materials for long-lasting performance.

Additional Details

The Molex 87832-5623 connector housing is designed to be used with Molex Micro-Latch crimp terminals. These terminals are crimped onto the wires and then inserted into the housing. The housing provides insulation and protection for the terminals and ensures proper alignment when mated with a corresponding header or receptacle. The Micro-Latch mechanism provides a tactile click when the connector is properly mated, indicating a secure connection.

The specific configuration of the 87832-5623, including the number of circuits, may vary. Refer to the Molex datasheet for detailed specifications and compatibility information. The connector is designed for automated assembly processes to enhance manufacturing efficiency.
