The Molex 87833-4420 is a Milli-Grid Connector Housing designed for wire-to-board connections requiring high density and reliable performance. As part of the Molex Milli-Grid series, this housing offers a compact footprint and secure mating, making it ideal for applications where space is limited and dependable connections are crucial. Its design facilitates ease of assembly and ensures optimal electrical contact.

Applications:

• Computer and Server Systems
• Networking Equipment (Routers, Switches, etc.)
• Industrial Automation Equipment
• Medical Devices
• Automotive Electronics
• Telecommunications Equipment
• Consumer Electronics (Printers, Scanners, etc.)

Features:

• 2.00mm Pitch: Allows for high-density connections in a small space.
• Dual Row, 40 Circuits: Provides a high number of connections in a compact form factor.
• Positive Lock: Ensures a secure and reliable connection, preventing accidental disconnections.
• Polarization: Prevents mismating, ensuring correct orientation during connection.
• High-Temperature Material: Constructed from materials that can withstand reflow soldering processes.
• RoHS Compliant: Meets environmental regulations restricting the use of hazardous substances.

Benefits:

• High Density: Enables a large number of connections in a small area, crucial for miniaturized devices.
• Reliable Connection: The positive lock feature provides a secure connection, even in high-vibration environments.
• Automated Assembly: Designed for automated pick-and-place assembly, reducing manufacturing time and costs.
• Prevents Errors: Polarization features prevent incorrect mating and potential damage.
• Durable Performance: High-quality materials ensure long-term reliability and consistent performance.

Additional Details:

The 87833-4420 housing is designed to work with specific crimp terminals within the Molex Milli-Grid series. These terminals provide a robust electrical connection with the wires, ensuring reliable signal transmission. The housing material is typically a high-temperature thermoplastic, allowing it to withstand the high temperatures encountered during reflow soldering processes. Proper alignment and mating with the appropriate header are essential for optimal performance.

This connector housing contributes to efficient and cost-effective manufacturing processes. Its compact size and reliable performance make it a popular choice in industries requiring high-density and dependable connections. The positive lock feature ensures that the connection remains secure, even under mechanical stress or vibrations.

The Molex 87833-4420 Milli-Grid Connector Housing offers a high-density, reliable solution for wire-to-board connections, making it well-suited for a variety of applications demanding compact and secure interconnects.
