Same model may have multiple batches, images only for reference.
90120-0129 Real Image
Same model may have multiple batches, images only for reference.

90120-0129

Part No 90120-0129
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 2.54mm Pitch C-Grid III Header, Single Row, Vertical, 9 Circuits, Tin (Sn) Plating
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Gender Male
Contact Material Brass
Contact Mating Length 6.7564 mm
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin SK
Current Rating 3 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Lead Free Lead Free
Lead Pitch 2.54 mm
Max Operating Temperature 125 °C
Max Voltage Rating (DC) 350.35 kV
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 9
Number of Contacts 9
Number of Lines 1
Number of Poles 9
Number of Positions 9
Number of Rows 1
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating 350 V
Voltage Rating (DC) 350 V
Win Source Part Number 1216647-90120-0129
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 90120-0129 CAD Model

Description

The Molex 1216647-90120-0129 is a male pin connector that has nine positions and a pitch of 2.54 mm.

  • Positions: Nine
  • Pitch: 2.54 mm
  • Color: Black
  • Category: Circular connectors - housings
  • Win Source Part Number: 1216647-90120-0129
  • Popularity: Medium
  • Lead-Free: Yes
  • RoHS Compliant: Yes
  • HTSUS Code: 8536.90.4000
