QA03 MORNSUN Science& Technology Ltd.
Same model may have multiple batches, images only for reference.

QA03

Part No QA03
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER FOR IGBT DRIVER,
Sample
Rohs State Need to verify
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr MORNSUN Science& Technology Ltd.
Series QA
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 23.3V
Voltage - Input (Max) 24.7V
Voltage - Output 1 15V
Voltage - Output 2 -8.7V
Current - Output (Max) 80mA, 40mA
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 105°C (With Derating)
Efficiency 80%
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Size / Dimension 0.77" L x 0.39" W x 0.49" H (19.5mm x 9.8mm x 12.5mm)
Approval Agency CB, CE, cURus
Standard Number 60950-1; 62368-1
Standard Package 25 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 658531-QA03
Ultra Librarian 3D Model Ultra Librarian QA03 CAD Model

Description

The QA03 is an isolated module DC-DC converter from MORNSUN Science & Technology Ltd.

  • Series: QA
  • Applications: Power Supplies, Board Mount
  • Size: 0.77" L x 0.39" W x 0.49" H
  • Output Voltages: 15V and -8.7V
  • Maximum Output Current: 80mA and 40mA
  • Input Voltage Range: 23.3V to 24.7V
  • Efficiency: 80%
  • Voltage Isolation: 3 kV
  • Application: ITE (Commercial)
  • Standard Package: 25 pcs
  • Compliance: CB, CE, cURus
  • Temperature Range: -40°C to 105°C (with derating)
