WRA0512S-1WR2 MORNSUN Science& Technology Ltd.
Same model may have multiple batches, images only for reference.

WRA0512S-1WR2

Part No WRA0512S-1WR2
Catalog Power Supplies Board Mount DCDC Converters
Description ISOLATED MODULE DC DC CONVERTER
Sample
Rohs State rohs
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr MORNSUN Science& Technology Ltd.
Series WRA_S-1WR2 (1W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 9V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 42mA, 42mA
Power (Watts) 1 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off
Temperature Range - Operating -40°C ~ 85°C
Efficiency 76%
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Approval Agency CE, EN, UKCA
Standard Number 62368-1
Standard Package 22 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 697810-WRA0512S-1WR2
Ultra Librarian 3D Model Ultra Librarian WRA0512S-1WR2 CAD Model

Description

The 697810-WRA0512S-1WR2 is a power supply module from MORNSUN Science & Technology Ltd. It belongs to the WRA_S-1WR2 series, which is a 1W isolated module.

  • Series: WRA_S-1WR2
  • Power: 1W
  • Function: Remote On/Off
  • Size: 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
  • Application: ITE (Commercial)
  • Outputs: 2
  • Maximum Output Current: 42mA each
  • Input Voltage: 4.5V to 9V
  • Output Voltages: 12V and -12V
  • Efficiency: 76%
  • Mounting Type: Through-Hole
  • Package: 8-SIP Module
  • Leads: 7
  • Operating Temperature: -40°C to 85°C
  • Approvals: CE, EN, UKCA
  • Product Status: Active
