74HC32D,653

Name: 74HC32D,653
Brand: Nexperia USA Inc.
SKU: 815892
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	74HC32D,653
Manufacturer	Nexperia USA Inc.
Catalog	Logic - Gates and Inverters
Description	IC GATE OR 4CH 2-INP 14SO
Datasheet	74HC32D,653 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Logic - Gates and Inverters
Mfr	Nexperia USA Inc.
Series	74HC
Package	Tape & Reel
Product Status	Active
Logic Type	OR Gate
Number of Circuits	4
Number of Inputs	2
Voltage - Supply	2V ~ 6V
Current - Quiescent (Max)	2 µA
Current - Output High, Low	5.2mA, 5.2mA
Input Logic Level - Low	0.5V ~ 1.8V
Input Logic Level - High	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL	15ns @ 6V, 50pF
Temperature Range - Operating	-40°C ~ 125°C
Mounting Type	Surface Mount
Supplier Device Package	14-SO
Package / Case	14-SOIC (0.154", 3.90mm Width)
Base Product Number	74HC32
Standard Package	2,500 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	815892-74HC32D,653
Ultra Librarian 3D Model	Ultra Librarian 74HC32D,653 CAD Model

Alternative Products

Description

The 815892-74HC32D,653 is a 4-input OR gate integrated circuit (IC) from the 74HC series manufactured by Nexperia USA Inc.

It is designed for use in logic gate applications and is housed in a 14-SOIC package, suitable for surface mount mounting.
The IC operates @ a voltage supply ranging from 2V to 6V and has a maximum propagation delay of 15ns @ 6V with a maximum capacitive load of 50pF.
The output current is 5.2mA for both high and low states, while the quiescent current is only 2μA.
