BAT754A,215

Part No BAT754A,215
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 30V SOT23
Datasheet
BAT754A,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Anode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) (per Diode) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 600mV @ 100mA
Current - Reverse Leakage @ Vr 2μA @ 25V
Operating Temperature - Junction 125°C (Max)
Mounting SMD (SMT)
Case / Package TO-236AB (SOT23)
Win Source Part Number 1022192-BAT754A,215
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BAT754A,215 CAD Model

Description

The Nexperia USA Inc. BAT754A,215 is a Schottky diode pair with a maximum DC reverse voltage of 30V and a forward voltage of 600mV @ 100mA.

  • Maximum DC Reverse Voltage: 30V
  • Forward Voltage: 600mV @ 100mA
  • Diode Configuration: 1 pair common anode
  • Average Rectified Current per Diode: 200mA
  • Current Reverse Leakage: 2μA @ 25V
  • Maximum Junction Temperature: 125°C
  • Package: SMD (SMT)
  • Package Type: TO-236AB (SOT23)
  • Popularity: Popular
  • Supply and Demand Status: Sufficient
