BC807-40HVL

Part No BC807-40HVL
Manufacturer Nexperia USA Inc.
Catalog Transistors (BJT) - Single
Description BC807-40H/SOT23/TO-236AB / Bipolar (BJT) Transistor PNP 45 V 500 mA 80MHz 320 mW Surface Mount TO-236AB
Datasheet
BC807-40HVL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - Bipolar (BJT) - Single
Mfr Nexperia USA Inc.
Series Automotive, AEC-Q101
Package Tape & Reel
Transistor Type PNP
Current - Collector (Ic) (Max) 500 mA
Voltage - Collector Emitter Breakdown (Max) 45 V
Vce Saturation (Max) @ Ib, Ic 700mV @ 50mA, 500mA
Current - Collector Cutoff (Max) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 250 @ 100mA, 1V
Power - Max 320 mW
Frequency - Transition 80MHz
Temperature Range - Operating 175°C (TJ)
Mounting SMD (SMT)
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package TO-236AB
Base Product Number BC807
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0095
Other Names 934660831235,1727-8602-2,1727-8602-1,1727-8602-6
Standard Package 10,000
Win Source Part Number 1048386-BC807-40HVL
Ultra Librarian 3D Model Ultra Librarian BC807-40HVL CAD Model

Description

The BC807-40HVL is a PNP bipolar transistor designed for discrete semiconductor products such as single transistors.

  • Maximum Power: 320mW
  • Voltage Collector Emitter Breakdown: 45V
  • Maximum Collector Current: 500mA
  • Vce Saturation (Max) @ Ib, Ic: 700mV @ 50mA, 500mA
  • Current Collector Cutoff (Max): 100nA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 250 @ 100mA, 1V
  • Frequency-Transition: 80MHz
  • Package: TO-236-3, SC-59, SOT-23-3
  • Temperature Range: 175°C (TJ)
  • Manufacturer: Nexperia USA Inc.
