HEF4066BT,653 Nexperia USA Inc. HEF4066BT,653 label picture HEF4066BT,653 real image
Same model may have multiple batches, images only for reference.
HEF4066BT,653 Nexperia USA Inc. HEF4066BT,653 label picture HEF4066BT,653 real image
HEF4066BT,653 Nexperia USA Inc. HEF4066BT,653 label picture HEF4066BT,653 real image
Same model may have multiple batches, images only for reference.

HEF4066BT,653

Part No HEF4066BT,653
Manufacturer Nexperia USA Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Analog Switch Quad SPST 14-Pin SO T/R / IC SWITCH QUAD 1X1 14SOIC
Datasheet
HEF4066BT,653 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Switch Circuit SPST - NO
Number of Circuits 4
Max On Resistance 155 Ohm
Channel-to-Channel Matching (ΔRon) 5 Ohm
Single Supply Voltage (V+) 3 V to 15 V
-3db Bandwidth 90MHz
Channel Capacitance(CS off, CD off) 7.5pF
Max Leakage Current (IS off) 200nA
Crosstalk -50dB @ 1MHz
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 14-SO
Win Source Part Number 1043122-HEF4066BT,653
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name HEF4066B
Introduction Date January 01, 1995
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HEF4066BT,653 CAD Model

Description

The Nexperia USA Inc. HEF4066BT,653 is a SPST-NO switch circuit component with a -3db bandwidth of 90MHz and a channel-to-channel matching of 5 Ohm.

  • Circuit Type: SPST-NO Switch
  • -3dB Bandwidth: 90MHz
  • Channel-to-Channel Matching: 5 Ohm
  • Maximum On Resistance: 155 Ohm
  • Channel Capacitance: 7.5pF
  • Temperature Range: -40°C to 125°C
  • Single Supply Voltage: 3V to 15V
  • Package: 14-SO
  • Mounting Type: SMD (SMT)
