NX2301P,215 Nexperia USA Inc. NX2301P,215 real image
Same model may have multiple batches, images only for reference.
NX2301P,215 Nexperia USA Inc. NX2301P,215 real image
NX2301P,215 Nexperia USA Inc. NX2301P,215 real image
Same model may have multiple batches, images only for reference.

NX2301P,215

Part No NX2301P,215
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 2A TO-236AB
Datasheet
NX2301P,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.1V @ 250μA
Max Gate Charge 6nC @ 4.5V
Max Input Capacitance 380pF @ 6V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 400mW (Ta), 2.8W (Tc)
Maximum Rds On at Id,Vgs 120 mOhm @ 1A, 4.5V
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-236AB (SOT23)
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 1084180-NX2301P,215
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian NX2301P,215 CAD Model

Description

The Nexperia USA Inc. MOSFET is a P-Channel transistor with a maximum power dissipation of 400mW (Ta), 2.8W (Tc).
