NX3008NBKW,115

Part No NX3008NBKW,115
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V SOT323
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 350mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 1.1V @ 250μA
Max Gate Charge 0.68nC @ 4.5V
Max Input Capacitance 50pF @ 15V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 260mW (Ta), 830mW (Tc)
Maximum Rds On at Id,Vgs 1.4 Ohm @ 350mA, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-323-3
Dimension SC-70, SOT-323
Win Source Part Number 1084188-NX3008NBKW,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian NX3008NBKW,115 CAD Model

Description

NX3008NBKW,115 from Nexperia USA Inc. is an RF MOSFET listed in the Transistors - FETs, MOSFETs - RF category and is suited for designs where engineers need compact semiconductor switching or amplification elements in radio-frequency signal paths. Devices in this class are commonly evaluated for wireless infrastructure, RF driver stages, signal conditioning, test equipment, and other high-frequency circuit applications where stable sourcing and compliance documentation matter alongside electrical performance. For design teams, the value of this part is its positioning within a recognized RF transistor family from an established manufacturer, making it relevant for both new product evaluation and maintenance sourcing. The current lifecycle status for NX3008NBKW,115 is information not available, so engineers should confirm latest production status directly with Nexperia or the official datasheet before locking it into a long-life program. RoHS compliance information is also not available in the provided data and should be verified through manufacturer documentation before procurement.
