NX3008PBKS,115 Nexperia USA Inc. NX3008PBKS,115 label picture
Same model may have multiple batches, images only for reference.
NX3008PBKS,115 Nexperia USA Inc. NX3008PBKS,115 label picture
NX3008PBKS,115 Nexperia USA Inc. NX3008PBKS,115 label picture
Same model may have multiple batches, images only for reference.

NX3008PBKS,115

Part No NX3008PBKS,115
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2P-CH 30V 0.2A 6TSSOP
Datasheet
NX3008PBKS,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
FET Type 2 P-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 200mA
Maximum Rds On at Id,Vgs 4.1 Ohm @ 200mA, 4.5V
Gate-Source Threshold Voltage 1.1V @ 250μA
Max Gate Charge 0.75nC @ 4.5V
Max Input Capacitance 46pF @ 15V
Maximum Power Dissipation 445mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-TSSOP
Win Source Part Number 1084189-NX3008PBKS,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian NX3008PBKS,115 CAD Model

Description

The NX3008PBKS,115 is a dual P-channel MOSFET that is designed for use in various applications.

  • Maximum Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 200mA @ 25°C
  • Gate-Source Threshold Voltage: 1.1V @ 250μA
  • Input Capacitance: 46pF @ 15V
  • Maximum Rds On: 4.1 Ohm @ 200mA and 4.5V
  • Popularity: medium popularity
  • Supply and demand status: sufficient.
