PDTC123ET,215 Nexperia USA Inc. PDTC123ET,215 real image17446
Same model may have multiple batches, images only for reference.
PDTC123ET,215 Nexperia USA Inc. PDTC123ET,215 real image17446
PDTC123ET,215 Nexperia USA Inc. PDTC123ET,215 real image17446
Same model may have multiple batches, images only for reference.

PDTC123ET,215

Part No PDTC123ET,215
Manufacturer Nexperia USA Inc.
Catalog RF Transistors (BJT)
Description TRANS PREBIAS NPN 50V TO236AB / Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased 50 V 100 mA 250 mW Surface Mount TO-236AB
Datasheet
PDTC123ET,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - Bipolar (BJT) - Single, Pre-Biased
Mfr Nexperia USA Inc.
Package Tape & Reel
Transistor Type NPN - Pre-Biased
Current - Collector (Ic) (Max) 100 mA
Voltage - Collector Emitter Breakdown (Max) 50 V
Resistor - Base (R1) 2.2 kOhms
Resistor - Emitter Base (R2) 2.2 kOhms
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 20mA, 5V
Vce Saturation (Max) @ Ib, Ic 150mV @ 500µA, 10mA
Current - Collector Cutoff (Max) 1µA
Power - Max 250 mW
Mounting SMD (SMT)
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package TO-236AB
Base Product Number PDTC123
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0095
Other Names PDTC123ET T/R-ND,PDTC123ET,215-ND,568-11245-1-ND,568-11245-2-ND,568-11245-2,1727-1705-6,568-11245-1,1727-1705-2,568-11245-6,1727-1705-1,PDTC123ET T/R,934054697215,568-11245-6-ND
Standard Package 3,000
Win Source Part Number 989801-PDTC123ET,215
Ultra Librarian 3D Model Ultra Librarian PDTC123ET,215 CAD Model

Description

The PDTC123ET,215 is an NPN pre-biased bipolar transistor with a collector-emitter voltage breakdown of 50V and a maximum collector current of 100mA.

  • Transistor Type: NPN Pre-Biased Bipolar
  • Collector-Emitter Voltage Breakdown: 50V
  • Maximum Collector Current: 100mA
  • Maximum Power Rating: 250mW
  • Packaging: Tape and Reel
  • Standard Package: 3000
  • DC Current Gain (hFE): 30 @ 20mA, 5V
  • Vce Saturation: 150mV @ 500μA, 10mA
  • Resistor-Base: 2.2 kOhms
  • Resistor-Emitter Base: 2.2 kOhms
  • Application: Automotive
  • Maximum Operating Temperature: 150°C
