PEMD3,115 Nexperia USA Inc. PEMD3,115 label picture
Same model may have multiple batches, images only for reference.
PEMD3,115 Nexperia USA Inc. PEMD3,115 label picture
PEMD3,115 Nexperia USA Inc. PEMD3,115 label picture
Same model may have multiple batches, images only for reference.

PEMD3,115

Part No PEMD3,115
Manufacturer Nexperia USA Inc.
Catalog Transistors (BJT) - Arrays, Pre - Biased
Description TRANS PREBIAS NPN/PNP SOT666
Datasheet
PEMD3,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Transistor Polarity 1 NPN, 1 PNP - Pre-Biased (Dual)
Maximum Current Collector 100mA
VCEO Maximum Collector-Emitter Breakdown Voltage 50V
Resistor - Base (R1) (Ohms) 10k
Resistor - Emitter Base (R2) (Ohms) 10k
Typical Gain (hFE) (Min) 30 @ 5mA, 5V
Max Vce (sat) 150mV @ 500μA, 10mA
Collector Cut-off Current(Max) 1μA
Maximum Power Dissipation 300mW
Mounting SMD (SMT)
Case / Package SOT-666
Win Source Part Number 1087480-PEMD3,115
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PEMD3,115 CAD Model

Description

The Nexperia USA Inc. PEMD3,115 is a dual NPN and PNP pre-biased transistor that is used in various applications.

  • Popularity: Medium-popularity
  • Series: SOT-666
  • Resistor Base (R1): 10k ohm
  • Resistor Emitter Base (R2): 10k ohm
  • Maximum Power Dissipation: 300mW
