PESD5Z6.0,115 Nexperia USA Inc. PESD5Z6.0,115 Real Image
Same model may have multiple batches, images only for reference.
PESD5Z6.0,115 Nexperia USA Inc. PESD5Z6.0,115 Real Image
PESD5Z6.0,115 Nexperia USA Inc. PESD5Z6.0,115 Real Image
Same model may have multiple batches, images only for reference.

PESD5Z6.0,115

Part No PESD5Z6.0,115
Manufacturer Nexperia USA Inc.
Catalog TVS - Diodes
Description TVS DIODE 6VWM 18VC SOD523
Datasheet
PESD5Z6.0,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 6V (Max)
Minimum Breakdown Voltage 6.8V
Max Clamping Voltage 18V
Peak Pulse Current(Ippm) 10A (8/20μs)
Power Dissipation - Pd 180W
Applications Ethernet
Capacitance @ Frequency 78pF @ 1MHz
Temperature Range - Operating -65°C to 150°C (TA)
Mounting SMD (SMT)
Case / Package SOD-523
Win Source Part Number 1087637-PESD5Z6.0,115
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PESD5Z6.0,115 CAD Model

Description

The Nexperia PESD5Z6.0,115 is a unidirectional zener diode that is designed for use in Ethernet applications.

  • Stand-off Voltage: 6V
  • Minimum Breakdown Voltage: 6.8V
  • Peak Pulse Current: 10A
  • Clamping Voltage: 18V
  • Package: SOD-523
  • Ideal for: Space-constrained designs
  • RoHS Compliant: Yes
  • Temperature Range: -65°C to 150°C
