NJM2536AM NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM2536AM

Part No NJM2536AM
Manufacturer Nisshinbo Micro Devices Inc.
Catalog Linear - Video Processing
Description IC VIDEO RF MOD 14DMP / Video Modulator IC 14-DMP Package
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Linear - Video Processing
Mfr Nisshinbo Micro Devices Inc.
Package Tube
Product Status Obsolete
Function Modulator
Voltage - Supply 4.5V ~ 5.5V
Mounting Type Surface Mount
Package / Case 14-SOIC (0.209", 5.30mm Width)
Supplier Device Package 14-DMP
Standard Package 50 pcs
MSL Level 2 (1 Year)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 254498-NJM2536AM
Ultra Librarian 3D Model Ultra Librarian NJM2536AM CAD Model

Description

The NJM2536AM is a video processing integrated circuit (IC) from Nisshinbo Micro Devices Inc.

  • Application: Specifically for modulator functions
  • Supply Voltage Range: 4.5V to 5.5V
  • Package: 14-SOIC package
  • Width: 0.209 inches (5.30mm)
  • Mounting Type: Suitable for surface mount applications
  • Status: Obsolete product and is no longer in production
  • Control Interface: Not specified
