NRF51822-QFAA-R7 Real Image NRF51822-QFAA-R7 real image4089
Same model may have multiple batches, images only for reference.
NRF51822-QFAA-R7 Real Image NRF51822-QFAA-R7 real image4089
NRF51822-QFAA-R7 Real Image NRF51822-QFAA-R7 real image4089
Same model may have multiple batches, images only for reference.

NRF51822-QFAA-R7

Part No NRF51822-QFAA-R7
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description Bluetooth SMART SOC 2Mbps 3V 48-Pin QFN EP T/R / IC RF TXRX+MCU BLUETOOTH 48VFQFN
Datasheet
NRF51822-QFAA-R7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Nordic Semiconductor ASA
Packaging Reel - TR
Status Active
Type TxRx + MCU
RF Family/Standard Bluetooth, General ISM > 1GHz
Protocol Bluetooth v4.0
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 4dBm
Sensitivity -96dBm
Memory Size 256kB Flash, 16kB RAM
Serial Interfaces I2C, SPI, UART
GPIO 32
Supply Voltage - Operating 1.8 V to 3.6 V
Current - Receiving 9.7mA to 13.4mA
Current - Transmitting 4.7mA to 16mA
Temperature Range - Operating -25°C to 75°C
Dimension 48-VFQFN Exposed Pad
Win Source Part Number 106484-NRF51822-QFAA-R7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name nRF51822
Country of Origin Philippines, Taiwan
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian NRF51822-QFAA-R7 CAD Model

Description

The NRF51822-QFAA-R7 from Nordic Semiconductor ASA is a TxRx + MCU electronic component that operates at a frequency of 2.4GHz.

  • Frequency: 2.4GHz
  • Protocol: Bluetooth v4.0
  • Memory Size: 256kB Flash, 16kB RAM
  • Output Power: 4dBm
  • Sensitivity: -96dBm
  • Data Rate: 2Mbps
  • Supply and Demand Status: Balanced
