1N4762A Transys Electronics
Same model may have multiple batches, images only for reference.

1N4762A

Part No 1N4762A
Manufacturer NTE
Catalog Diodes - Zener - Single
Description DIODE ZENER 82V 1W AXIAL
Datasheet
1N4762A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr NTE
Package Bag
Product Status Active
Voltage - Zener (Nom) (Vz) 82 V
Tolerance ±0.5%
Power - Max 1 W
Impedance (Max) (Zzt) 200 Ohms
Current - Reverse Leakage @ Vr 5 µA @ 62.2 V
Temperature Range - Operating -65°C ~ 20°C
Mounting Type Through Hole
Package / Case Axial
Supplier Device Package Axial
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 539144-1N4762A
Ultra Librarian 3D Model Ultra Librarian 1N4762A CAD Model

Description

The NTE 1N4762A is a single zener diode with a voltage rating of 82V and a power rating of 1W.

  • Package: Bag
  • Status: Active product
  • Tolerance: ±0.5%
  • Reverse Leakage Current: 5μA @ 62.2V
  • Impedance: 200 ohms
  • Mounting: Through-hole
  • Operating Temperature: -65°C to 20°C
  • ECCN: EAR99
  • HTSUS Code: 8541.10.0050
