The 2N7002BK is a high-performance, small-signal N-channel Field-Effect Transistor (FET) produced by NXP Semiconductors. This MOSFET is designed to deliver efficient power control and switching in a compact SOT-23 package, making it an ideal choice for space-constrained applications that require low-power operation and high-speed switching capabilities.

Key Features

• Low On-Resistance: The 2N7002BK offers a low on-state resistance, typically around 7.5 ohms, which enhances its efficiency by minimizing power loss during operation.
• High-Speed Switching: With fast switching speeds, this MOSFET is suitable for high-frequency applications, providing quick response times for precise control.
• Low Threshold Voltage: A low threshold voltage ensures that the device can be easily driven by low-voltage logic signals, making it compatible with a variety of control circuits.
• Low Gate Drive Requirements: The 2N7002BK can be operated with minimal gate drive power, which reduces the overall power consumption of the system it's integrated into.
• High Continuous Drain Current: It supports a continuous drain current of up to 115 mA, allowing it to handle moderate power loads efficiently.

Applications

The versatility of the 2N7002BK makes it suitable for a wide range of applications, including:

• Power Management Circuits
• DC/DC Converters
• Load/Power Switching
• Motor Control Systems
• Logic Level Conversion
• Portable Devices

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and reliability. The 2N7002BK MOSFET is no exception, having undergone rigorous testing and quality control measures to ensure it meets the highest industry standards. Users can trust in the durable performance and longevity of this component in their electronic designs.

Environmental Compliance

The 2N7002BK is compliant with RoHS (Restriction of Hazardous Substances) directives, ensuring that it is manufactured with a focus on environmental safety and sustainability. This compliance reflects NXP's dedication to reducing the environmental impact of its products and meeting global regulatory requirements.
