Product Overview: 74ALVC164245DL,118

The 74ALVC164245DL,118 is a high-performance, low-voltage CMOS device manufactured by NXP Semiconductors. It is part of the advanced 74ALVC family, designed to offer both high speed and low power consumption. This integrated circuit is a 16-bit dual-supply transceiver featuring non-inverting 3-state bus compatible outputs.

Key Features

• Logic Family: The device belongs to the ALVC family, which is well-known for its low voltage operation and compatibility with TTL levels.
• Operating Voltage: It operates at a very low voltage ranging from 1.65V to 3.6V, making it suitable for battery-powered and portable devices.
• High-Speed Performance: With the capability to support data transfer rates, the 74ALVC164245DL,118 is ideal for high-speed data communication and processing applications.
• Bus Hold Function: The device includes a bus hold feature which helps in retaining the last known state of the data line when no input is present.
• Low Power Consumption: It is designed for minimal power consumption, which is crucial for energy-sensitive applications.
• Wide Bus Interface: The 16-bit bus interface width allows for efficient data movement and is great for parallel data transfer scenarios.

Product Applications

The 74ALVC164245DL,118 is versatile and can be used in a variety of applications. It is particularly useful in interfacing applications where different voltage domains need to communicate with each other. Some common applications include:

• Server and telecom infrastructure
• Portable and battery-powered devices
• Data communication systems
• Computing and data storage systems
• Signal bridging between different voltage domains

Technical Specifications

• Package: The device comes in a TSSOP-48 (Thin Shrink Small Outline Package) which is suitable for surface-mount technology.
• Temperature Range: It operates within an industrial temperature range, ensuring reliability under varying environmental conditions.
• Compliance: The product is compliant with JEDEC standard no. 8-1A.
• ESD Protection: It includes protection against electrostatic discharge, enhancing the durability of the device.

With its robust feature set, the 74ALVC164245DL,118 from NXP Semiconductors is an excellent choice for designers looking for a reliable and efficient solution for high-speed bidirectional communication between two voltage domains.
