Product Overview: MC10ELT24DR2G

The MC10ELT24DR2G is a high-performance, differential ECL to TTL translator manufactured by ON Semiconductor. This integrated circuit is designed to bridge the gap between two of the most common logic families, enabling seamless communication and signal translation in mixed-voltage systems. The device is particularly well-suited for applications that require high-speed data transmission and low power consumption.

Key Features

• Logic Conversion: The device converts ECL (Emitter Coupled Logic) levels to TTL (Transistor-Transistor Logic) levels, ensuring compatibility between systems operating at different voltage standards.
• High-Speed Performance: With a typical propagation delay of only 2.0 ns, the MC10ELT24DR2G is optimized for high-speed applications that demand rapid signal processing.
• Power Efficiency: It operates with a low supply voltage of 5 V ±5% and features a significantly reduced power consumption compared to similar devices, making it ideal for power-sensitive designs.
• Temperature Range: The device is designed to operate over an industrial temperature range of -40°C to +85°C, ensuring reliability and performance under varying environmental conditions.
• Package: Available in an 8-pin SOIC package, the MC10ELT24DR2G is compact and suitable for space-constrained applications.

Applications

With its versatile features, the MC10ELT24DR2G is used in a wide array of applications, including but not limited to:

• High-speed data communication systems
• Networking and telecommunication equipment
• Signal conversion and interfacing in mixed-voltage environments
• Digital signal processing
• Computer motherboards and servers

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MC10ELT24DR2G is no exception. It is manufactured to the highest standards to ensure consistent performance and longevity. Designers and engineers can trust this device for their critical applications where reliable logic level translation is crucial.
