The CD4093BM96G4 is a highly versatile and reliable integrated circuit manufactured by Texas Instruments. This particular device belongs to the 4000 series of CMOS logic ICs and features quad 2-input NAND Schmitt triggers. It is designed to operate with a supply voltage ranging from 3V to 15V, making it suitable for a wide array of applications in both digital and analog circuits.

Key Features

• Logic Type: NAND Gate Schmitt Trigger
• Number of Circuits: 4
• Inputs per Circuit: 2
• Supply Voltage Range: 3V to 15V
• Output Current: -8.8 mA, 10 mA
• Mounting Type: Surface Mount
• Package / Case: SOIC-14
• Operating Temperature: -55°C to +125°C

Applications

The CD4093BM96G4 is suitable for various applications, including:

• Wave and pulse shapers
• High-noise-environment systems
• Monostable multivibrators
• ASTABLE multivibrators
• Logic circuits
• Signal processing

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the CD4093BM96G4 is no exception. This device is built to meet or exceed the stringent requirements of the automotive, industrial, and consumer markets. Its wide temperature range ensures reliable operation in extreme conditions, and its CMOS technology offers low power consumption, which is essential for battery-powered devices.

Environmental Compliance

The CD4093BM96G4 is RoHS compliant and is free from lead, ensuring it meets the environmental standards set for electronic components. Texas Instruments is dedicated to sustainable manufacturing practices, and this product reflects their ongoing efforts to minimize the environmental impact of their products.
