Product Overview: 74HC4060PW by NXP

The 74HC4060PW is a high-performance, integrated circuit designed and manufactured by NXP Semiconductors. It is a 14-stage binary ripple counter with an oscillator, encapsulated in a TSSOP16 (Thin Shrink Small Outline Package with 16 pins) type package, which is suitable for surface-mounted device (SMD) technology.

This versatile chip is part of the 74HC (High-Speed CMOS) family, which is well-known for its robustness and compatibility with TTL (Transistor-Transistor Logic). The 74HC4060PW boasts a wide operating voltage range from 2V to 6V, making it ideal for a variety of applications that require precise timing and counting operations, including consumer electronics, office automation, and data processing systems.

Key Features:

• Oscillator Configuration: The integrated oscillator is configurable with an external resistor and capacitor, giving the user flexibility in setting the desired oscillation frequency.
• Counter Stages: The counter features 14 stages, leading to a wide division range, and includes an internal oscillator.
• Output Capability: The 74HC4060PW provides standard outputs which can drive up to 10 LSTTL (Low-power Schottky TTL) loads, ensuring compatibility with various logic families.
• High Noise Immunity: The inherent design of the CMOS technology offers high noise immunity, making the device reliable in electrically noisy environments.
• Low Power Consumption: As a CMOS device, it has a significantly low power consumption, especially when compared to its TTL counterparts.

Applications:

The device is suitable for a broad range of timing and counter applications, including but not limited to:

• Frequency dividers
• Time-delay circuits
• Counter or timer in industrial and consumer electronics
• Real-time clocks
• Sequential state machines

The 74HC4060PW by NXP is a testament to the company's commitment to delivering high-quality, reliable components that meet the demanding needs of the modern electronics industry. With its flexible design and robust performance, the 74HC4060PW is an essential building block for any timing and counting solutions.
