Product Overview: 74HCT574D by NXP Semiconductors

The 74HCT574D is a high-quality, advanced technology product from NXP Semiconductors, a leader in the electronic components industry. This particular device is an octal D-type flip-flop that features positive edge-triggered operation, making it an essential component for a wide range of digital applications.

Designed with the cutting-edge High-Speed CMOS technology, the 74HCT574D offers a perfect blend of high-speed performance and low power consumption. It is compatible with TTL levels, which allows for easy integration into various systems without the need for additional interfacing components.

The 74HCT574D comes in a robust SOIC-20 package, ensuring a compact footprint on printed circuit boards (PCBs) and providing reliability even in demanding environments. This makes it suitable for use in industrial, commercial, and even some harsh applications where space is at a premium and performance is critical.

Key Features:

• Logic Type: Octal D-type flip-flop with positive-edge trigger
• Operating Voltage: 4.5V to 5.5V, making it ideal for 5V logic systems
• Output Capability: Standard outputs with a high drive capability
• Package: SOIC-20, offering a space-saving design
• Pin Configuration: The device includes 20 pins, with 8 data inputs (D0 to D7), 8 outputs (Q0 to Q7), as well as clock (CP), output enable (OE), and ground (GND) pins
• Compatibility: TTL input level compatibility for seamless integration

Applications:

The 74HCT574D is highly versatile and can be used in a variety of digital circuits. Common applications include:

• Temporary data storage
• Data transfers and multiplexing
• System control functions
• Interface between mismatched clock domains

With its reliable performance and NXP's commitment to quality, the 74HCT574D is an excellent choice for designers and engineers looking for a dependable flip-flop solution. Its ease of use, combined with its powerful features, ensures that it can meet the needs of sophisticated digital systems while maintaining a simple and efficient design footprint.
