Product Overview: 74LVC1G08GV - NXP Semiconductors

The 74LVC1G08GV is a high-performance, single 2-input AND gate IC, manufactured by NXP Semiconductors. This logic gate is part of the 74LVC family, which is well-known for its low-voltage operation and compatibility with mixed-voltage system environments. The 74LVC1G08GV operates with a supply voltage range of 1.65V to 5.5V, making it versatile for various applications, from battery-powered devices to industrial control systems.

Key Features:

• Low Power Consumption: The device has been optimized for low power consumption, which is critical for extending the battery life of portable applications.
• High-Speed Operation: Despite its low power design, the 74LVC1G08GV does not compromise on speed, offering high-speed operation that is typical of the LVC family.
• 5V Tolerant Inputs: Inputs can tolerate up to 5V, even when the device is operating at a lower voltage, providing design flexibility and protecting against higher voltage transients.
• Wide Operating Temperature: The device functions across a broad temperature range, from -40°C to +125°C, suitable for demanding environments.
• Compatibility: It is compatible with TTL levels, allowing for easy integration into systems that use older technology without the need for level shifting.

Applications:

The 74LVC1G08GV is ideal for a variety of applications where space is at a premium and low power is necessary. These include, but are not limited to:

• Mobile Phones
• PDAs
• Portable Media Players
• Portable Gaming Devices
• Industrial Control Systems
• Medical Equipment

Package Information:

The device is offered in a small outline package, specifically in a 5-pin SOT753 (SC-74A) package. This compact form factor is excellent for space-constrained applications and contributes to the miniaturization of the end product.

Quality and Reliability:

NXP Semiconductors is committed to delivering high-quality products. The 74LVC1G08GV is subjected to rigorous testing and quality control processes to ensure reliability and performance in the field.
