The PCA9555AHF,128 is a robust, high-performance integrated circuit (IC) designed and manufactured by NXP Semiconductors. This IC is part of the family of I²C-bus GPIO (General Purpose Input/Output) expanders that are known for their ease of use and versatility in various applications. The PCA9555AHF,128 is particularly suitable for applications where additional I/Os are needed, and it is widely used in the expansion of microcontroller functionalities.

Key Features

• I²C Interface: The device features a fast I²C bus (Inter-Integrated Circuit) interface with a maximum clock frequency of 400 kHz, allowing for quick communication with microcontrollers or other I²C devices.
• 16-bit I/O Ports: It has two 8-bit ports, totaling 16 I/Os, which can be independently configured as either inputs or outputs, providing flexibility for a wide range of applications.
• Interrupt Output: An interrupt output is available and is activated when any input state changes, providing an efficient way of monitoring the input changes without the need for constant polling by the microcontroller.
• Low Standby Current: The PCA9555AHF,128 is designed to have a low standby current, making it suitable for power-sensitive applications.
• Wide Operating Voltage: This device operates over a broad voltage range from 2.3 V to 5.5 V, making it compatible with both 3.3 V and 5 V logic levels.
• Polarity Inversion: Input port polarity can be inverted with the use of polarity inversion registers, enhancing the device's adaptability to the application's requirements.

Applications

The PCA9555AHF,128 is ideal for use in various applications that require additional I/Os. These include, but are not limited to:

• Servers
• Personal computers
• Embedded systems
• Industrial control
• Medical equipment
• Mobile communications

Package and Quality

The PCA9555AHF,128 comes in a TSSOP24 package, which is a thin shrink small outline package, offering a compact footprint for space-constrained applications. NXP's commitment to quality ensures that each IC is rigorously tested to meet the high standards required for a wide range of industrial and commercial uses.
