Product Overview: PSMN3R0-60BS MOSFET by NXP Semiconductors

The PSMN3R0-60BS is a high-performance N-channel enhancement-mode field-effect transistor (MOSFET) designed by NXP Semiconductors, a leader in the semiconductor industry. This MOSFET is part of NXP's extensive portfolio of efficient power solutions and is specifically engineered to meet the demanding requirements of modern electronic circuits.

Key Features

• Low On-Resistance: The PSMN3R0-60BS boasts an incredibly low on-resistance (R<sub>DS(on)) of just 3.0 mΩ at V<sub>GS = 10 V, which ensures minimal power loss and improved efficiency in operation.
• High Current Capability: With a continuous drain current (I<sub>D) of 100 A, this MOSFET can handle high current applications with ease, making it suitable for power-intensive tasks.
• 60V Drain-Source Voltage: The device can support a drain-source voltage (V<sub>DS) up to 60V, providing a good margin for a variety of electronic designs.
• Low Gate Charge: A low gate charge (Q<sub>G) enhances the switching performance, which is critical for high-speed applications.
• Robust Package: The PSMN3R0-60BS is housed in a durable LFPAK56 (Power-SO8) package, which not only offers a compact footprint but also excellent thermal performance.

Applications

The PSMN3R0-60BS is versatile and can be used in a wide range of applications, including:

• DC/DC converters
• Motor drives
• Power management systems
• Computing and server power supplies
• Automotive applications
• High-performance power switching circuits

Reliability and Performance

NXP's commitment to quality ensures that the PSMN3R0-60BS MOSFET delivers not only in terms of performance but also reliability. It is designed to withstand harsh conditions and is characterized by a robust thermal performance, which contributes to its longevity and stable operation over a wide temperature range.

Whether you are designing a sophisticated power supply or looking to enhance the efficiency of a motor control application, the PSMN3R0-60BS from NXP Semiconductors is a choice that promises to deliver high efficiency, reliability, and performance.
