NXP PTN3460BS/F3 DisplayPort to LVDS Bridge

The NXP PTN3460BS/F3 is a high-performance, low-power DisplayPort to LVDS bridge designed to connect a DisplayPort source to an LVDS display panel. It is an ideal solution for video interface conversion applications in a wide range of products, including notebooks, ultrabooks, tablets, docking stations, and monitors.

This compact bridge IC is capable of converting a single DisplayPort (DP) input into a single Low Voltage Differential Signaling (LVDS) output. The PTN3460BS/F3 supports a wide range of data rates up to 2.7 Gbps per lane and is compatible with DisplayPort version 1.1a, ensuring high compatibility with existing DisplayPort sources.

One of the key features of the PTN3460BS/F3 is its support for up to 24-bit color depths and a maximum resolution of 1920 x 1200 pixels, offering a high-quality visual experience. Additionally, it integrates a programmable LVDS output swing and an emphasis feature, enabling fine-tuning for specific display requirements and ensuring signal integrity over cables.

The device is also equipped with an advanced power management system, including a smart power-saving mode that significantly reduces power consumption when the display is inactive or disconnected. This makes the PTN3460BS/F3 an environmentally friendly choice for energy-conscious designs.

For ease of use, the PTN3460BS/F3 is available in a small footprint package, making it suitable for space-constrained applications. Furthermore, it requires minimal external components, which simplifies the design and reduces the overall bill of materials.

Developers will appreciate the built-in EDID buffer that eliminates the need for an external EEPROM for EDID storage, streamlining the design process. NXP also provides comprehensive support and documentation, including datasheets, application notes, and reference designs, to facilitate the integration of the PTN3460BS/F3 into various platforms.

In summary, the NXP PTN3460BS/F3 is a versatile and efficient solution for bridging DisplayPort to LVDS, offering excellent display performance, power efficiency, and ease of design that is well-suited for a broad range of applications in today's display-centric world.
