The PTN36001HX is a high-performance, low-power USB 3.0 redriver from NXP Semiconductors designed to enhance signal quality by performing receive equalization on the deteriorated input signal followed by transmit de-emphasis, maximizing system link performance. This versatile device is an ideal solution for applications requiring high-speed data transmission over long and challenging PCB traces or cables.

Key Features

• USB 3.0 Compliance: The PTN36001HX supports SuperSpeed USB 3.0 data rates of 5 Gbps, ensuring compatibility with the latest USB standards and high-speed data transfer capabilities.
• Integrated Redriver: The built-in redriver technology helps to recover signal integrity and extend the reach of USB 3.0 connections without sacrificing performance.
• Low Power Consumption: Designed with power efficiency in mind, the PTN36001HX operates with minimal power consumption, making it suitable for battery-powered devices.
• Adjustable Equalization and De-emphasis: It offers programmable receive equalization and transmit de-emphasis levels to optimize performance for various channel conditions.
• Small Form Factor: The compact size of the PTN36001HX allows for easy integration into space-constrained designs without compromising functionality.

Applications

The PTN36001HX is an excellent choice for a wide range of applications, including:

• Notebooks and Ultrabooks
• Desktop and All-in-One PCs
• Tablets and Mobile Devices
• Docking Stations
• USB 3.0 Hubs and Peripherals

Technical Specifications

With its robust design and advanced features, the PTN36001HX from NXP is a reliable and cost-effective solution for enhancing USB 3.0 connectivity in a multitude of electronic devices.
