The NXP TJA1051T/3/CM is a high-speed Controller Area Network (CAN) transceiver, designed to provide an interface between a CAN protocol controller and the physical two-wire CAN bus. As part of NXP's high-performance automotive networking solutions, this robust transceiver is engineered to operate in harsh automotive environments, offering excellent electromagnetic compatibility (EMC) and electrostatic discharge (ESD) performance.

Key Features

• Improved CAN FD Performance: Compatible with the ISO 11898-2:2016 standard, the TJA1051T/3/CM supports CAN with Flexible Data rates (CAN FD) for faster data transmission and improved bandwidth utilization.
• Low Power Consumption: Features a very low stand-by current and an even lower sleep current, making it suitable for energy-sensitive applications.
• Robustness: Designed for use in automotive applications, this transceiver can withstand the challenging conditions of the automotive environment, including handling of high-voltage transients and automotive electromagnetic interference.
• High ESD Protection: Offers integrated ESD protection for the CANH and CANL bus pins, providing system-level ESD immunity.
• Silent Mode: In silent mode, the transmitter is disabled, allowing the transceiver to monitor CAN bus activity without influencing it, which is critical for diagnostic or power-saving functions.

Applications

The TJA1051T/3/CM is particularly suitable for a wide range of automotive applications where high data rate and/or high reliability of data transmission are required. This includes powertrain systems, chassis control modules, advanced driver assistance systems (ADAS), and infotainment systems. Its robust design also makes it a good choice for industrial automation and control systems where similar robustness is required.

Package Information

The device is offered in an 8-pin SOIC package, providing a compact footprint that is ideal for space-constrained applications. The package is designed to optimize the thermal performance and reliability necessary for automotive and industrial applications.

Ordering and Sample Information

For ordering or requesting samples of the NXP TJA1051T/3/CM, interested parties should contact NXP sales representatives or authorized distributors. Detailed product information and support documentation can be found on the NXP website.
