The UDA1380TT/N2,512 is a high-quality, low-power audio codec from NXP Semiconductors designed to deliver exceptional audio performance for a wide range of applications. This versatile IC integrates both digital-to-analog converter (DAC) and analog-to-digital converter (ADC) functions, making it an ideal solution for portable and stationary audio systems.

Key Features

• High-Quality Audio: The UDA1380TT/N2,512 features a 24-bit DAC and ADC, providing high-resolution audio with a dynamic range that ensures crystal-clear sound reproduction.
• Low Power Consumption: With its focus on energy efficiency, this audio codec is perfect for battery-powered devices, helping to extend the battery life while maintaining high audio fidelity.
• Multiple Audio Interfaces: It supports I2S, LSB-justified, MSB-justified, and DSP digital audio interfaces, offering great flexibility for various audio applications.
• On-chip Headphone Driver: The built-in headphone driver can directly drive stereo headphones, simplifying design and reducing component count.
• Flexible Sampling Rates: The device supports a wide range of sampling rates from 8 kHz to 96 kHz, accommodating different quality requirements and audio formats.

Applications

The UDA1380TT/N2,512 is suitable for a diverse array of products, including but not limited to:

• Portable audio players
• MP3 players
• Personal digital assistants (PDAs)
• Sound cards and audio interfaces
• Home audio systems
• Automotive audio systems

Technical Specifications

Some of the primary technical specifications for the UDA1380TT/N2,512 include:

• Voltage Supply: 2.7V to 3.6V
• Dynamic Range (DAC): 100 dB
• Dynamic Range (ADC): 92 dB
• THD+N (Total Harmonic Distortion + Noise): -86 dB
• Packaging: SMD (Surface-Mount Device)

Ordering Information

The product is available in a 48-lead LQFP package and can be ordered using the part number UDA1380TT/N2,512. For purchasing information, datasheets, and technical support, customers are encouraged to contact NXP Semiconductors or authorized distributors.
