D5A-3300 Real Image
Same model may have multiple batches, images only for reference.

D5A-3300

Part No D5A-3300
Manufacturer Omron
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACT SPST-NC 10MA 24V / Switch SPST-NC Panel Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Limit Switches
Manufacturer Omron Automation and Safety
Packaging Bulk
Circuit SPST-NC
Switch Function On-Mom
Current Rating (Amps) 10mA (AC/DC)
Voltage Rating - AC 24 V
Voltage Rating - DC 12 V
Actuator Type Round (Pin Plunger)
Mounting Panel Mount
Termination Style Cable Leads
Ingress Protection IP67 - Dust Tight, Waterproof
Features Cable Length 1m
Operating Force 100gf
Differential Travel 0.0002" (0.005mm)
Overtravel 0.060" (1.5mm)
Temperature Range - Operating -20°C ~ 75°C
Operating Position 0.256" (6.5mm)
Electrical Life 1,000,000 Cycles
Mechanical Life 10,000,000 Cycles
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.9055
Other Part Number D5A3300,Z7353,D5A-3300-ND
Standard Package 1
Win Source Part Number 1323780-D5A-3300
Ultra Librarian 3D Model Ultra Librarian D5A-3300 CAD Model

Description

The Omron Automation and Safety D5A-3300 is a limit switch with an on-mom switch function and a SPST-NC circuit.

  • Cable Length: 1m
  • Ingress Protection: IP67
  • Operating Temperature: -20°C to 75°C
  • Voltage Rating: 24V AC and 12V DC
  • Mechanical Life: 10,000,000 cycles
  • Electrical Life: 1,000,000 cycles
