Same model may have multiple batches, images only for reference.
G6B-2214P-US-DC24 Real Image
Same model may have multiple batches, images only for reference.

G6B-2214P-US-DC24

Part No G6B-2214P-US-DC24
Manufacturer Omron
Catalog Power Relays, Over 2 Amps
Description General Purpose Relay, G6B Series, Power, Non Latching, DPST-NO, 24 VDC, 5 A RoHS Compliant: Yes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Ambient Temperature Range High 70 °C
Approvals CSA, UL
Mounting SMD (SMT)
Case / Package DIP
Coil Current 12.5 mA
Coil Power 300 mW
Coil Resistance 1.92 kΩ
Coil Type Non-Latching
Coil Voltage (DC) 24 V
Contact Current Rating 5 A
Contact Material Cadmium, Silver
Current Rating 5 A
Depth 11 mm
Height 11 mm
Lead Free Yes
Length 20 mm
Max Current Rating 5 A
Maximum Operating Temperature 70 °C
Max Voltage Rating (AC) 380 V
Max Voltage Rating (DC) 125 V
Min Operating Temperature -25 °C
Mount PCB, Through Hole
Number of Contacts 2
Number of Pins 6
Operate Time 10 ms
Power Consumption 200 mW
Radiation Hardening No
Relay Type General Purpose
Release Time 10 ms
RoHS Compliant
Switching Current 5 A
Termination PC Pin
Throw Configuration DPST
Voltage Rating (AC) 380 V
Voltage Rating (DC) 125 V
Weight 4.5 g
Win Source Part Number 1060294-G6B-2214P-US-DC24
Categories Power Relays,Over 2 Amps
Manufacturer Omron
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian G6B-2214P-US-DC24 CAD Model

Description

The Omron G6B-2214P-US-DC24 power relay is a general-purpose, non-latching relay that is designed for use in industrial applications.

  • Termination: PC pin
  • Contact Material: Cadmium silver
  • Current Rating: 5 A
  • Coil Resistance: 1.92 kΩ
  • Coil Current: 12.5 mA
  • Throw Configuration: DPST
  • Maximum Voltage: 380 V AC and 125 V DC
  • Maximum Operating Temperature: 70 °C
  • Minimum Operating Temperature: -25 °C
  • RoHS Compliant: Yes
  • Lead-Free: Yes
  • Mounting: PCBs and through-hole
  • Series: G6B series of power relays
  • Approvals: CSA and UL
