The 1SMB5916BT3G is a robust voltage regulator Zener diode from ON Semiconductor, designed for applications requiring voltage regulation and surge protection. This high-performance device is a popular choice for a wide range of electronic circuits, providing precision voltage control and reliability in a compact SMB package.

Key Features

• Voltage Range: The 1SMB5916BT3G offers a broad range of nominal Zener voltages from 3.3 V to 47 V, making it suitable for various applications.
• Power Dissipation: With a power dissipation of 3 W, this Zener diode can withstand significant voltage transients and provides a stable reference voltage.
• High Surge Capability: Designed to handle surge events, this device can protect sensitive circuit components from voltage spikes and electrical transients.
• Package: The SMB package is not only space-efficient but also offers excellent thermal performance, ensuring the diode operates within its specified temperature range.
• Tolerance: The Zener voltage tolerance is ±5%, which allows for precise voltage regulation in critical applications.

Applications

The 1SMB5916BT3G is versatile and can be used in numerous applications. It is particularly suited for:

• Voltage regulation modules
• Overvoltage protection circuits
• Switching power supplies
• Other types of power management systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the 1SMB5916BT3G is no exception. It is produced with the high manufacturing standards that ON Semiconductor is renowned for, ensuring both high quality and reliability for your electronic designs.

Environmental Compliance

The 1SMB5916BT3G complies with RoHS (Restriction of Hazardous Substances) directives, making it an environmentally friendly choice for manufacturers looking to create green products.
